The Allen-Bradley 1768-EWEB is a powerful web server module for the CompactLogix series. This unit lets you remotely monitor and modify control system data. It uses XML web pages for a flexible interface. The module fits perfectly into plant management applications. It also excels at high-speed data collection on Ethernet/IP networks. You can use it for internet or intranet connections too.
Product Procurement & Buyer Guide
The 1768-EWEB module provides a direct path to enhanced data visibility. It allows engineers to access real-time controller information. Procurement managers value its robust connection capabilities. The module supports up to 64 TCP/IP connections simultaneously. It also handles a full 128 CIP connections for data exchange. This device communicates at a reliable speed of 10/100 Mbps. You can place it into slot 3 or slot 4 of the 1768 bus. It works specifically with the 1769-L45 controller system. This compatibility ensures seamless integration into existing architectures.
The module consumes just 4.34 Watts of power during operation. It provides an isolation voltage of 30 Volts for safety. The unit weighs approximately 7.5 ounces for easy handling. You can mount it on a panel or install it on a DIN rail. The flash file system offers 2 MB of storage space. This space stores custom web pages and data views. The module uses an 802.3 compliant twisted pair connection. It requires a standard RJ45 Category 5 interface cable. This setup makes installation straightforward for any technician.
The 1768-EWEB comes in two series, A and B, for flexibility. Status LED displays provide clear operational feedback at a glance. The module includes one Ethernet port for network connectivity. It has zero motion axes as a dedicated web server. The unit ships with a weight of 2 pounds in packaging. Its shipping dimensions are 8 x 8 x 5 inches. The module has a storage capacity of 2 MB for web content. This data allows for comprehensive remote monitoring solutions.
Step-by-Step User & Installation Guide
First, power down the entire control system before installation. Locate an available slot in the CompactLogix 1768 bus. Insert the 1768-EWEB module into slot 3 or slot 4. Ensure the module locks securely into place on the bus. You can also mount it on a DIN rail for flexibility. Alternatively, you can panel mount the module for permanent installation. Connect an 802.3 compliant shielded or unshielded twisted pair cable. Use a standard RJ45 Category 5 interface for the connection.
Next, apply power to the control system to start the module. Observe the status LED displays for proper boot-up sequence. The module will establish communication at 10/100 Mbps automatically. Configure the module to support your required TCP/IP connections. The device can handle up to 64 TCP/IP connections reliably. It also supports 128 CIP connections for comprehensive data flow. Use the flash file system to upload your custom XML web pages. Store your data views in the available 2 MB of space.
Finally, test the remote monitoring capability from a network computer. Access the module via its assigned IP address on the network. Verify that you can view and modify control system data. Check that all 128 CIP connections are functioning correctly. Monitor the power consumption to confirm it stays at 4.34 Watts. Ensure the isolation voltage remains at 30 Volts for safety. The module provides a reliable interface for plant management applications. This setup allows for effective data collection on a single network.
Logistics & Standard Packaging Details
- One Allen-Bradley 1768-EWEB Enhanced Web Server Module
- The unit comes in series A or B configuration as ordered
- Product packaging includes standard anti-static protection materials
- Shipping weight is approximately 2 pounds per unit
- Shipping dimensions are 8 x 8 x 5 inches per package
- The module weighs 7.5 ounces without any enclosure
- Express delivery shipping is available via FedEx, UPS, and DHL
