Product Summary
The 1763-L16BWA MicroLogix 1100 controller provides a compact automation solution. It integrates 16 discrete I/O points plus two analog inputs. This unit handles small-scale applications with high reliability. Its built-in Ethernet port simplifies network connectivity.
Product Procurement & Buyer Guide
The 1763-L16BWA controller is a cost-effective choice for simple machines. It uses a universal AC input power supply from 120 to 240 Volts. This flexibility reduces the need for separate power converters. The unit features ten 24V DC digital inputs for sensor integration. Four of these inputs operate at high speed for counting tasks. This capability supports precise motion and positioning applications.
The controller includes two 0-10VDC analog inputs for process signals. These inputs offer a 10-bit resolution for accurate data conversion. Engineers can connect 2-wire, 3-wire, or 4-wire transmitters easily. The six isolated relay outputs handle loads up to 3A per group. Each relay provides a mechanical life of 10,000,000 cycles for durability.
This model supports up to four expansion modules for future growth. The built-in RS-232/485 and Ethernet ports enable flexible communication. Its non-volatile battery-backed RAM preserves your program during power loss. The integrated LCD display shows real-time status and diagnostic data. This simplifies troubleshooting and reduces machine downtime.
The controller operates reliably in harsh environments from -20 to 65 degrees Celsius. It withstands operational shock of 30G and vibration of 15G. These ratings ensure stable performance on vibrating machinery. The compact dimensions of 3.5 x 4.33 x 3.43 inches save valuable panel space. This makes the 1763-L16BWA ideal for tight control cabinets.
When wiring analog inputs, use Belden 8761 shielded cable for noise immunity. Connect the drain wire and foil shield to your grounding system. The analog channels do not provide loop power for external transmitters. You must supply power separately for 2-wire and 4-wire devices. The relay outputs operate with a voltage range of 125VDC or 120-240VAC.
The input channels have an OFF-state voltage range between 0 and 5 Volts DC. The maximum OFF-state leakage current is 1.5 mA for reliable signal detection. The nominal input impedance is 3.1 kΩ for standard digital sensors. The analog inputs provide +/-0.5% full-scale non-linearity for measurement accuracy. The input voltage protection handles up to 10.5 Volts DC safely.
The relay contacts have a MAKE current capacity of 1.2A for inductive loads. The continuous current rating is 1.0A for sustained operation. The make power output is 28VA for switching small motors or solenoids. The turn OFF and turn ON response time is 10 milliseconds for fast actuation. This ensures precise control over output devices in your process.
The controller has an inrush current of 25A for 8 milliseconds at 120 Volts AC. At 240 Volts AC, the inrush current is 40A for 4 milliseconds. The overall power consumption is 52 VA for efficient energy use. The operating frequency range is 47 to 63 Hertz for global compatibility. This makes the unit suitable for use in different regional power grids.
The analog input resolution is 10-bit with an unsigned integer data type. The input coding uses a 10-bit signed integer for voltage signals. The analog voltage range is 0-10VDC with a 210 kΩ voltage impedance. This high impedance prevents signal loading from the sensor. The input accuracy is +/-0.5% for reliable process monitoring.
The digital inputs support both sinking and sourcing wiring configurations. This flexibility allows connection to various sensor types without adapters. The four high-speed inputs handle pulse trains up to several kilohertz. Use these inputs for encoder feedback or high-speed counting applications. The standard inputs handle general-purpose limit switches and pushbuttons.
The relay output channels are designed for a load current of 10A maximum. The mechanical life of 10,000,000 cycles ensures long-term reliability. Each relay is individually isolated for independent switching of different circuits. This isolation prevents cross-talk between output channels in your system. The relay outputs switch both AC and DC loads for maximum versatility.
Logistics & Standard Packaging Details
- One Allen-Bradley 1763-L16BWA MicroLogix 1100 Programmable Controller
- Product is packaged in anti-static protective material for safe transit
- Original Rockwell Automation packaging with part number label
- We ship express delivery via FedEx, UPS, and DHL for fast arrival
