The 1784-PCIDS is a DeviceNet PCI card from Rockwell Automation. It belongs to the Allen-Bradley PLC 5 series. This card connects industrial devices to a PC. It uses the DeviceNet protocol for communication. The card requires a PCI rev. 2.1 slot. It operates at 5 Volts DC and 625 milliamps.
Latest Developments and Updates
- The 1784-PCIDS is available in Series A and Series B.
- It has an input image table capacity of 2048 bytes.
- Its output image table capacity is also 2048 bytes.
- The card requires 2 MB of disk space for installation.
- It operates at temperatures from 32 to 131 degrees Fahrenheit.
Market Impact and Industry Analysis
The 1784-PCIDS supports the DeviceNet protocol, which is common in manufacturing. This card helps integrate older PLC 5 systems with modern PCs. Its open enclosure design allows for flexible installation. Moreover, its wide operating temperature range suits harsh factory environments. Therefore, the card remains relevant for legacy system upgrades.
Practical Industry Applications
The 1784-PCIDS is used in factory automation for data exchange. It connects sensors, actuators, and controllers to a PC. For example, it can monitor production lines or control conveyors. In addition, its 2048-byte image tables support moderate data volumes. This makes it suitable for small to medium-sized DeviceNet networks.
Expert Recommendations and Next Steps
Engineers should verify the PCI slot version before installation. The card requires a 5V, 32-bit short PCI slot. Furthermore, users must ensure the PC meets power requirements. The operating temperature range is 32 to 131 degrees Fahrenheit. Storage temperature should be between -40 and 185 degrees Fahrenheit. Consequently, proper environmental controls are essential for reliable operation.
Frequently Asked Questions
What is the 1784-PCIDS?
The 1784-PCIDS is a DeviceNet PCI card from Rockwell Automation. It belongs to the Allen-Bradley PLC 5 series.
What are the power requirements for this card?
The card requires 5 Volts DC and 625 milliamps. Therefore, check your PC power supply capacity.
What is the input image table capacity of the 1784-PCIDS?
The input image table capacity is 2048 bytes. Similarly, the output image table holds 2048 bytes.
What operating temperature range does the card support?
The card operates from 32 to 131 degrees Fahrenheit. Consequently, it suits most industrial environments.
What PCI slot does the 1784-PCIDS require?
It requires a PCI rev. 2.1 slot. Specifically, it is a 5V, 32-bit short card.
