Why the 170INT11000 Matters for Your Network
In modern industrial facilities, reliable data transmission is the backbone of efficient operations. The Schneider Electric 170INT11000 communication adapter, part of the Modicon Momentum series, provides a robust solution for Interbus networks. This buyer's guide helps you evaluate whether this module meets your specific application needs.
With the push toward Industry 4.0 and smart manufacturing, legacy fieldbus systems like Interbus remain critical for many installed bases. The 170INT11000 offers a dependable bridge for these networks, ensuring seamless communication between controllers and field devices.
Key Technical Specifications at a Glance
Understanding the technical parameters is essential before making a purchase decision. Here are the critical specifications for the 170INT11000, sourced directly from the manufacturer's data:
- Communication Protocol: Interbus Generation SUPI II
- Transmission Rate: 500 kilobits per second
- Transmission Cable: Twisted pairs cable
- Network Topology: Ring network
- Electrical Connection: Two 9-pin D-Sub Interbus connectors
- Access Method: Master/Slave and continuous shift register
- Devices per Segment: 0 to 254
- Maximum Cable Distance: More than 3,280 feet (1,000 meters) between devices; 1,312.14 feet (400 meters) between two modules
- Control Parameter: CRC-16
- Power Dissipation: 0.8 Watt (without fiber-optic adapter)
- Power Consumption: Less than 200 to 400 milliamperes at 5 Volts DC
- Protection Class: IP20
- Ambient Operating Temperature: 0 to 60°C (non-condensing)
- Storage Temperature: -40 to 85°C (non-condensing)
Applications and Use Cases
The 170INT11000 is designed for industrial environments where deterministic communication is required. Its ring topology and Master/Slave access method make it suitable for applications such as material handling, packaging lines, and process control systems.
For example, in a typical bottling plant, the adapter can link multiple sensors and actuators to a central controller, ensuring real-time data exchange. The ability to support up to 254 devices per segment allows for scalable network designs without compromising performance.
Integration with Existing Systems
Integration is straightforward thanks to the two 9-pin D-Sub Interbus connectors. These connectors enable quick connection to existing Interbus cabling, minimizing installation time. The adapter's support for twisted pairs cable aligns with common industrial wiring practices.
When integrating the 170INT11000 into a Modicon Momentum automation platform, you can leverage the existing infrastructure. The adapter's fail-safe state and CRC-16 error checking ensure data integrity, reducing the risk of communication errors.
Real-World Scenario: A Hypothetical Example
Consider a mid-sized automotive parts manufacturer that operates a legacy Interbus network. They need to replace a faulty communication adapter without overhauling the entire system. The 170INT11000 fits seamlessly, offering the same protocol and transmission rate, thus minimizing downtime and avoiding costly rewiring.
This scenario illustrates the adapter's value as a drop-in replacement, preserving the existing network architecture while restoring full functionality.
Business Value and ROI
Investing in the 170INT11000 can yield significant returns. Its low power consumption—less than 200 to 400 milliamperes at 5 V DC—reduces energy costs over time. The robust design, with an IP20 protection class and wide temperature range, ensures long-term reliability, minimizing unplanned downtime.
Moreover, the adapter's support for long cable runs (over 3,280 feet) allows for flexible plant layouts, potentially reducing the need for additional infrastructure. This translates into lower total cost of ownership.
Frequently Asked Questions
What is the maximum number of devices I can connect per segment?
The 170INT11000 supports 0 to 254 devices per segment, giving you flexibility to design networks of varying sizes.
Can I use this adapter with existing Interbus cabling?
Yes, the adapter uses twisted pairs cable, which is standard for Interbus networks. The two 9-pin D-Sub connectors ensure compatibility with typical Interbus connections.
What is the operating temperature range?
The adapter operates in ambient temperatures from 0 to 60°C in non-condensing conditions. For storage, it can withstand -40 to 85°C.
Does the 170INT11000 support ring topology?
Yes, the adapter is designed for ring network topology, which is a key requirement for many industrial applications.
Why Choose SpareTechPLC?
SpareTechPLC specializes in industrial automation spare parts, offering genuine products like the Schneider 170INT11000. We understand the importance of reliable components for your operations. Our team can assist with product selection and provide fast shipping to minimize downtime.
Contact SpareTechPLC today to order the 170INT11000 and ensure your network runs smoothly.
