Keyence KV-N14DTP PLC Controller 24 VDC PNP

Keyence KV-N14DTP PLC Controller – 24 VDC Source Output for Small Machines

The KV-N14DTP delivers reliable logic control in tight panel spaces. Keyence designed this KV Nano unit as a terminal-block type controller. It provides 8 input points and 6 transistor output points on one base unit. Engineers pick this model when the panel runs on 24 VDC and the wiring needs source (PNP) outputs. Moreover, the built-in RS-232C port connects easily to HMIs and host devices.

Technical Specifications

The KV-N14DTP offers an 8k program capacity. Basic instruction execution starts at 50 ns. Application instructions run at 170 ns. Furthermore, the controller accepts expanded ladder, KV Script, and mnemonic programming. Two positioning pulse outputs reach 100 kHz per axis. Besides that, two 32-bit high-speed counters handle 100 kHz single-phase or 50 kHz phase-difference signals.

I/O and Communication Details

The base unit includes 8 inputs and 6 outputs. Users can attach up to 3 expansion units through the backplane. This raises total capacity to 128 I/O points. Meanwhile, the RS-232C modular connector supports KV STUDIO and no-protocol serial links. Communication modules also extend options via the backplane slot.

Electrical and Environmental Data

The KV-N14DTP accepts a 24 VDC nominal supply with +/-10% tolerance. A 24 VDC output supply delivers 0.6 A. Outputs use MOSFET transistors in source (PNP) mode, rated 30 VDC at 0.5 A per point. Operating temperature ranges from 0 to +55 °C without freezing. Storage temperature spans -25 to +75 °C. In addition, humidity tolerance covers 5 to 95% RH without condensation.

Installation Guide

First, mount the unit on a DIN rail or panel inside a clean enclosure. Next, wire the 24 VDC supply to the marked terminals. Then connect input signals and output loads following the terminal diagram. Keep high-voltage cables away from signal lines to reduce noise. Finally, set the communication parameters in KV STUDIO and run a test program.

Packaging List

• 1 × Keyence KV-N14DTP PLC unit

• 1 × Terminal block connector set

• 1 × Installation guide

FAQ

Q1: What supply voltage does the KV-N14DTP require?
A: The KV-N14DTP runs on a 24 VDC nominal supply with +/-10% tolerance.

Q2: What distinguishes it from the KV-N14DT?
A: The KV-N14DT uses sink (NPN) outputs, while the KV-N14DTP provides source (PNP) outputs.

Q3: How many positioning axes does this PLC support?
A: It provides 2 pulse output axes at a maximum of 100 kHz each.

Q4: Can I expand the I/O beyond 8 inputs and 6 outputs?
A: Yes, the backplane accepts up to 3 expansion units for 128 total points.

Q5: How is the product shipped?
A: We ship via Fedex, UPS, and DHL with tracking provided.
