Keyence IV4-L5C White LED Ring Light Unit

Product Introduction

The IV4-L5C functions as an external lighting solution for Keyence's IV4 Series smart cameras. Specifically, this ring light provides consistent white LED illumination. It enables the camera to capture clear images for inspection tasks. Furthermore, its rugged construction ensures reliable performance in industrial environments.

Technical Specifications

This external light unit relies on the connected sensor for power. Therefore, no separate power supply is required. The IV4-L5C uses white LEDs as its illumination source. Moreover, the unit is compatible with the IV4-500CA sensor model. Keyence designed this integration for seamless operation. Additionally, the light unit does not include built-in communication ports or protocols.

Mechanical and Environmental Parameters

The IV4-L5C features a durable aluminum die-casting case. Besides, the front cover uses acrylic material for optical clarity. The unit weighs approximately 195 grams. It meets ESD safety standards, specifically IEC61340-5-1. In terms of environmental resistance, the enclosure rating reaches IP67. However, this rating applies only when attached to the applicable sensor. It also excludes scenarios where polarizing filters are installed. Meanwhile, the operating temperature ranges from 0 to +50°C without freezing. The relative humidity tolerance remains at 85% RH or less, without condensation.

Installation Guide

First, verify the sensor model is IV4-500CA before installation. Next, remove the protective cap from the sensor's light port. Then, align the IV4-L5C ring light with the mounting thread. Afterward, rotate the unit clockwise until it sits securely. Additionally, ensure the connection is tight to maintain the IP67 rating. For optimal performance, keep the acrylic front cover clean. Finally, avoid installing polarizing filters if the IP67 rating is required.

Packaging List

• 1x Keyence IV4-L5C External Light Unit

• 1x Original Packaging Box

• 1x Installation Guide

FAQ

Q1: What is the compatible sensor for the IV4-L5C?
A: This ring light unit is designed specifically for the Keyence IV4-500CA smart camera.

Q2: Does the IV4-L5C require a separate power supply?
A: No. The unit receives power directly from the connected IV4 smart camera sensor.

Q3: Is the IP67 rating always guaranteed with this light unit?
A: The IP67 rating only applies when attached to the compatible sensor. It does not apply when polarizing filters are installed.

Q4: What materials make up the IV4-L5C housing?
A: The main case uses aluminum die-casting, and the front cover is acrylic.

Q5: How do I receive this product?
A: We ship globally via Fedex, UPS, and DHL.
