The 6GK5206-2BS00-2AC2 belongs to the SCALANCE XC-200 product family, a series of fully managed industrial Ethernet switches from Siemens. This particular model, the XC206-2SFP, combines copper and fiber connectivity in a compact, rugged enclosure. It serves as a backbone for factory automation, process control, and critical infrastructure networks.
Furthermore, this switch supports advanced Layer 2 functions, including VLANs, RSTP, MRP, and PRP. These features ensure high network availability and fast recovery from link failures. Additionally, the device carries IEC 62443-4-2 certification, which confirms its compliance with international security standards for industrial automation systems. Its extended temperature range and multiple mounting options make it suitable for harsh environments.
The SCALANCE XC206-2SFP provides 6 integrated RJ45 ports supporting 10/100 Mbit/s. Each port includes a securing collar for robust cable retention. For fiber connections, it offers 2 SFP slots that accept both 100 Mbit/s and 1000 Mbit/s SFP transceivers. This flexibility allows you to mix copper and fiber media as needed. A dedicated console port (RJ11) enables local configuration and diagnostics. Additionally, a 2-pole signaling contact provides alarm output for fault monitoring.
This switch features a redundant power supply input for increased reliability. It accepts a wide DC voltage range from 9.6 V to 31.2 V, with a nominal rating of 24 V DC. Typical power consumption is 6 W, and maximum current draw reaches 0.5 A. The built-in fuse (2.5 A / 125 V) protects the device against overcurrent conditions. A 4-pole terminal block simplifies wiring for both power inputs.
The 6GK5206-2BS00-2AC2 uses the store-and-forward switching method. It supports a maximum telegram length of 1632 bytes, which accommodates standard industrial data frames. For network management, it offers CLI, web-based management, and SNMP v1/v2/v3. It also supports RMON, port mirroring, and multiport mirroring for traffic analysis. PROFINET Conformance Class B ensures seamless integration with Siemens automation environments.
Network reliability stands as a core strength of this switch. It supports multiple redundancy protocols, including High Speed Redundancy Protocol (HRP) with redundancy manager and standby redundancy. Media Redundancy Protocol (MRP) and MRP Interconnection (MRP-I) are also available. Additionally, it supports STP, RSTP, RSTP+, MSTP, and Parallel Redundancy Protocol (PRP). Reconfiguration time for ring redundancy falls below 0.3 seconds, which minimizes downtime in critical applications.
Security features include IEEE 802.1x (RADIUS) for port-based authentication. The device also incorporates broadcast/multicast/unicast limiting and broadcast blocking to prevent network storms. For encrypted management access, it supports SSH and SSL protocols. These functions help protect your network from unauthorized access and cyber threats.
The switch measures 60 mm in width, 147 mm in height, and 125 mm in depth. It weighs 0.52 kg. The enclosure combines polycarbonate (PC-GF10) with die-cast aluminum, providing excellent mechanical strength and heat dissipation. You can mount it on a 35 mm DIN rail, an S7-300 rail, an S7-1500 rail, or directly on a wall. This versatility simplifies installation in various cabinet configurations.
The SCALANCE XC206-2SFP operates reliably from -40 °C to +70 °C. Storage and transport temperatures range from -40 °C to +85 °C. This wide temperature tolerance makes it suitable for outdoor cabinets, cold storage facilities, and desert installations. Relative humidity can reach 95% at 25 °C without condensation, ensuring performance in damp environments.
The device carries an IP20 protection rating, suitable for installation in control cabinets. It holds numerous international approvals, including CE, UL 61010-2-201, UL 60950-1, ATEX, IECEx, FM, and CCC for hazardous locations. Maritime approvals from ABS, BV, DNV GL, KRS, LRS, NK, PRS, and RINA further extend its application scope to shipboard and offshore installations. The MTBF rating of 47 years reflects high reliability.
First, select an appropriate mounting method based on your cabinet layout. For DIN rail mounting, snap the switch onto a 35 mm rail. For S7 rail mounting, use the compatible rails as specified. Alternatively, secure it to a wall using suitable screws. Ensure adequate clearance for cable connections and airflow.
Connect the DC power supply to the 4-pole terminal block. For redundant operation, connect both power inputs to separate sources. Observe correct polarity to avoid damage. The integrated fuse provides protection, but we recommend using an external circuit breaker for added safety.
Plug RJ45 cables into the 6 copper ports. Use shielded cables for industrial environments to minimize electromagnetic interference. For fiber connections, insert compatible SFP transceivers into the two slots. The switch automatically negotiates speed and duplex for each port. The console port (RJ11) allows serial access for initial setup and troubleshooting.
Access the switch via the console port or through the Ethernet network using a web browser. The web-based management interface provides an intuitive way to configure VLANs, redundancy protocols, and security settings. Alternatively, use the CLI for advanced configurations. For PROFINET environments, STEP 7 integration simplifies device setup and diagnostics.
1 x SCALANCE XC206-2SFP managed switch (6GK5206-2BS00-2AC2)
1 x 4-pole power supply terminal block (pre-installed)
1 x 2-pole signaling contact terminal block (pre-installed)
1 x Quick installation guide
Note: SFP transceivers, mounting accessories, and console cables are sold separately.
1. What is the difference between managed and unmanaged switches?
Managed switches like the SCALANCE XC206-2SFP allow configuration, monitoring, and redundancy setup. Unmanaged switches offer plug-and-play operation without configuration capabilities.
2. Can I use this switch in a PROFINET network?
Yes. The switch supports PROFINET Conformance Class B and works as a PROFINET IO device. It integrates seamlessly with Siemens TIA Portal and STEP 7 environments.
3. Which SFP transceivers are compatible with this switch?
The switch accepts both 100 Mbit/s and 1000 Mbit/s SFP transceivers. Siemens recommends using original SCALANCE SFP modules for guaranteed compatibility and performance.
4. What redundancy protocols does this switch support?
It supports MRP, HRP, PRP, STP, RSTP, RSTP+, and MSTP. These protocols provide fast recovery times and high network availability for critical applications.
5. Is this switch suitable for outdoor or extreme temperature applications?
Yes. The -40 °C to +70 °C operating temperature range and IP20 rating with robust enclosure make it suitable for outdoor cabinets and extreme industrial environments.
